High Temp High Alumina Insulation Brick Lightweight Insulating Fire Brick

Name: High Temp High Alumina Insulation Brick Lightweight Insulating Fire Brick
Brand: LEADSUN
Price: 1 USD

Buy cheap High Temp High Alumina Insulation Brick Lightweight Insulating Fire Brick product

Brand Name : LEADSUN

Model Number : INSULATION BRICK

Certification : ISO

Place of Origin : CHINA

MOQ : 500 pcs

Price : Negotiable

Payment Terms : L/C,D/P,T/T,Western Union

Supply Ability : 1000 tons/month

Delivery Time : 12 days

Packaging Details : Pallet

Refractoriness : 900-1500C

Size : 230*114*65mm 230*114*75mm

Density : 0.5-1.3g/cm3

Package : Pallet

Shape : Customizable

Color : White or Pink

Contact Now

High Temperature High Alumina Insulation Brick Lightweight Low Thermal Conductivity Energy Saving

Light Weight High Alumina Brick, also known as high-aluminium heat insulating brick, Light weight high alumina bricks contain more than 48% alumina oxide. The refractory temperature can reach 1770 degrees, and the usable temperature can reach 1550 degrees.which has such advantages as high porosity, small volume density, good insulation effect, high mechanical intensity, small thermal conductivity and long service life. For various industrial kilns & furnaces, it is a kind of essential refractory for energy saving and temperature preservation.

Introduction of High Alumina Insulation Brick

Light Weight High Alumina Brick, also known as high-aluminium heat insulating brick, are used in building heat insulating walls or heat preserving walls, which is basically for preserving or insulating heat. Light weight high alumina bricks contain more than 48% alumina oxide. This kind of brick does not directly exposed to high temperature inside kilns or furnaces, it only built closely to the kiln wall as insulations. It is a good insulation refractory material, which has a high compressive strength, low thermal conductivity and good insulation quality.

High Alumina Insulation Brick Features

1. High refractoriness, can reach 1650-1800ºC, can contact with the flame directly, suitable for various atmosphere.

2. High mechanical intensity.

3. Low levels of iron and other impurities.

4. Good thermal shock resistance.

5. Chemical stability.

6. High porosity, low volume density, good thermal insulation effect,energy-efficient.

7. Low thermal conductivity, stable quality.

8. Excellent thermal shock resistance.

9. Strong resistance to the corrosive gas and slag.

High alumina poly light insulation brick physical and chemical performance index

Brand

Items

LG-1.2

LG-1.0

LG-0.8

LG-0.7

LG-0.6

LG-0.5

Al2O3 %

≥48

≥48

≥48

≥48

≥48

≥48

Fe2O3 %

≤2

≤2

≤2

≤2

≤2

≤2

Bulk Density g/cm3

≤1.2

≤1.0

≤0.8

≤0.7

≤0.6

≤0.5

Cold Crush Strength,MPa

≥4.5

≥4.0

≥3.0

≥2.5

≥2.0

≥1.5

Permanent Linear Change Rate,%

1400℃×12h ≤2

1400℃×12h ≤2

1400℃×12h ≤2

1350℃×12h ≤2

1350℃×12h ≤2

1250℃×12h≤2

Thermal Conductivity W/(m·K)
350±25℃

≤0.55

≤0.50

≤0.35

≤0.35

≤0.30

≤0.25

Application of High Alumina Insulation BrickLight Weight High Alumina Brick is used in parts that is not exposed to abrasions and high temperature of melted matters. They should not be applied in environment that has a temperature higher than 1350ºC. .As a low price refractory material, the light weight high alumina bricks are applied in: .Furnace Lining And Insulation Layers .Ceramic Tunnel Kiln .Roller Kiln .Shuttle Kiln .Heating Furnace & Coking Furnace In Iron And Steel Industry .Other Thermal Equipment & Heat Treatment Lining
